Camera

• Image Sensor: 1/3″ Progressive Scan CMOS

• Max resolution: 2560 × 1440 (4MP)

• Main Stream:

  • 50 Hz: 20 fps (2560 × 1440), 25 fps (1920 × 1080, 1280 × 720)

  • 60 Hz: 20 fps (2560 × 1440), 24 fps (1920 × 1080, 1280 × 720)

• Substream:

  • 50 Hz: 25 fps (1280 × 720, 640 × 480, 640 × 360)

  • 60 Hz: 24 fps (1280 × 720, 640 × 480, 640 × 360)

• Video Compression:

  • Main stream: H.265+/H.265/H.264+/H.264

  • Sub-stream: H.265/H.264/MJPEG

• Video Bitrate: 32 Kbps to 8 Mbps

• Audio Compression: G.711/G.722.1/G.726/MP2L2/PCM/AAC-LC

• Audio Input: Built-in microphone, record with audio

• Audio Output: Built-in Speaker

• Lens: 2.8 mm

• Min. Illumination:

  • Color: 0.005 Lux @ (F1.6, AGC ON)

  • B/W: 0 Lux with IR

• Angle of View:

  • Horizontal FOV 98°, vertical FOV 54°, diagonal FOV 114°

• Supplement Light Type: IR, White Light

• Supplement Light Range: Up to 30 m

• Motion detection 2.0: Support, include Human & Vehicle detection

• Image Enhancement: BLC, HLC, 3D DNR

• Wide Dynamic Range: 120 dB WDR

• Protocols: TCP/IP, ICMP, DHCP, DNS, HTTP, RTP, RTSP, RTCP, NTP, IGMP, IPv4, IPv6, UDP, QoS, FTP, SMTP

• API: Open Network Interface (Profile S, Profile T, Profile G), ISAPI, SDK

• Region of Interest (ROI): 1 fixed region for main stream

• Privacy Mask: 4 programmable rectangle privacy masks

• General Function: Heartbeat, anti-banding, mirror, password protection, password reset via email

• Ethernet: 1 RJ45 10 M/100 M self-adaptive Ethernet port

General

• Housing: Metal

• Color: White

• Storage: Support on-board storage up to 512 GB (SD card slot)

• Hardware Reset: Yes

• Operating Power:

  • 12 VDC ± 25%, 0.66 A, max. 8 W, Ø 5.5 mm coaxial power plug, reverse polarity protection

  • PoE: IEEE 802.3af, Class 3, max. 9.5 W

• Operating Temperature: -22 °F – 140 °F / -30 °C – 60 °C

• Indoor/Outdoor Use: Indoor/Outdoor

• Interface Protection: IP67

• Dimension (L × W × H): 179 mm × 67.4 mm × 69.1 mm (7.1″ × 2.7″ × 2.7″)

• Weight: Approx. 450 g (1.0 lb.)
