Camera

• Image Sensor: 2 X 1/2.4″ Progressive Scan CMOS

• Max resolution: 4256 × 1888 (6MP)

• Main Stream:

  • 50 Hz: 20 fps (4256 × 1888)

  • 60 Hz: 20 fps (4256 × 1888)

• Substream:

  • 50 Hz: 20 fps (1200 × 536, 960 × 432)

  • 60 Hz: 20 fps (1200 × 536, 960 × 432)

• Video Compression:

  • Main stream: H.265+/H.265/H.264+/H.264

  • Sub-stream: H.265/H.264/MJPEG

• Video Bitrate: 32 Kbps to 16 Mbps

• Audio Compression: G.711/G.722.1/G.726/MP2L2/PCM/AAC-LC

• Audio Input: Built-in Microphone, record with audio

• Audio Output: 1 built-in speaker, Max. power consumption: 2 W, max. sound pressure level: 10 cm: 97 dB

• Day & Night: IR cut filter

• Lens: Fixed focal lens, 2 mm

• Min. Illumination: Color: 0.005 Lux @ (F1.6, AGC ON)

• Angle of View: Horizontal FOV 180°, vertical FOV 77°

• Supplement Light Type: IR, White Light

• Supplement Light Range: Up to 30 m

• Motion detection 2.0: Support, include Human and Vehicle Detection

• Image Enhancement: BLC, HLC, 3D DNR

• Wide Dynamic Range: 120 dB WDR

• Protocols: TCP/IP, ICMP, DHCP, DNS, HTTP, RTP, RTSP, RTCP, NTP, IPv4, IPv6, IGMP, UDP, QoS, FTP, SMTP

• API: ONVIF (Profile S, Profile T, Profile G), ISAPI, SDK

• Region of Interest (ROI): 1 fixed region for main stream

• Privacy Mask: 4 programmable rectangle privacy masks

• General Function: Heartbeat, anti-banding, mirror, password protection, password reset via email

General

• Housing: Base: Metal, cover: Plastic

• Color: White

• Ethernet: 1 RJ45 10 M/100 M self-adaptive Ethernet port

• Storage: Support on-board storage up to 512 GB (SD card slot)

• Hardware Reset: Yes

• Operating Power:

  • 12 VDC ± 25%, 0.83 A, max. 10 W, Ø 5.5 mm coaxial power plug, reverse polarity protection

  • PoE: IEEE 802.3af, Class 3, max. 11.5 W

• Operating Temperature: (-22 °F to 140 °F) / -30 °C to 60 °C. Humidity 95% or less (non-condensing)

• Indoor/Outdoor Use: Indoor/Outdoor

• Interface Protection: IP67

• Dimension (L × W × H): Ø 130.1 mm × 109.1 mm (Ø 5.1″ × 4.3″)

• Weight: Approx. 580 g (1.3 lb.)
