Intelligent Analytics

AI by Device: Facial recognition, perimeter protection, and Motion Detection 2.0.

AI by Camera: Facial recognition, perimeter protection, throwing object detection, Motion Detection 2.0, ANPR (Automatic Number Plate Recognition), and VCA (Video Content Analysis).

Facial Recognition

Face Picture Comparison: Supports 4 channels.

Facial Detection and Analytics: Includes human face capture, face picture comparison, and face picture search.

Face Picture Library: Up to 16 libraries storing 20,000 face pictures total (each ≤ 4 MB, max capacity 1 GB).

Detection Performance: 1 channel, 8 MP resolution.

Motion Detection 2.0

By camera on all channels.

By device across all channels with 4 MP video (up to 8 MP with enhanced SVC mode), for human and vehicle recognition to reduce false alarms.

Perimeter Protection

By device: 2 channels, 4 MP HD network camera video analysis (H.264/H.265) with human and vehicle detection to reduce false alarms.

By camera: applies to all channels.

Video and Audio

IP Video Input: 8 channels.

Incoming Bandwidth: 80 Mbps.

Outgoing Bandwidth: 160 Mbps.

HDMI Output: 1 channel supporting 4K (3840×2160)/30 Hz, 2K (2560×1440)/60 Hz, 1080p, and other resolutions.

VGA Output: 1 channel supporting up to 1920×1080/60 Hz.

Video Output Mode: HDMI and VGA independent outputs.

Audio Output: 1 channel RCA (2.0 Vp-p, 1 KΩ) from audio input.

Two-Way Audio: 1 channel RCA (Linear, 1 KΩ).

Decoding

Formats: H.265, H.265+, H.264+, H.264.

Recording Resolution: Supports from 12 MP down to QCIF.

Synchronous Playback: 8 channels.

Decoding Capability:

AI on: 2-ch@12 MP, 3-ch@8 MP, 6-ch@4 MP, 12-ch@1080p (30 fps).

AI off: 2-ch@12 MP, 4-ch@8 MP, 8-ch@4 MP, 16-ch@1080p (30 fps).

Stream Type: Video and Video & Audio.

Audio Compression: G.711ulaw, G.711alaw, G.722, G.726, AAC.

Network

Supports up to 128 remote connections.

API support: ONVIF (profile S/G), SDK, ISAPI.

Compatible with IE11, Chrome v57+, Firefox v52+, Safari v12+, Edge v89+.

Protocols: TCP/IP, DHCP, IPv4/IPv6, DNS, DDNS, NTP, RTSP, SADP, SMTP, SNMP, NFS, iSCSI, ISUP, UPnP™, HTTP, HTTPS.

Network interface: 1 RJ-45 10/100/1000 Mbps Ethernet port.

PoE

8 RJ-45 10/100 Mbps PoE ports.

Power consumption ≤ 80 W.

IEEE 802.3af/at standard compliant.

Auxiliary Interface

2 SATA interfaces supporting up to 16 TB per HDD.

Alarm In/Out: 4 inputs / 1 output.

USB ports: 1 front USB 2.0, 1 rear USB 2.0.

General

Power Supply: 48 VDC, 2.5 A.

Power Consumption: ≤ 15 W (without HDD and PoE off).

Operating Temperature: -10 °C to 55 °C (14 °F to 131 °F).

Operating Humidity: 10% to 90%.

Dimensions: 385 mm × 315 mm × 52 mm (15.2″ × 12.4″ × 2.0″).

Weight: ≤ 3 kg (6.6 lb.) without HDD.
