Camera
Image Sensor 1/2.5″ CMOS sensor
Image Resolution 8M:3840*2160 5M:2592*1944 4M:2560*1440 2M:1920*1080
TV System PAL/NTSC
Electronic Shutter Auto
Minimun Illumination Color : 0.03 lux@F2.0, AGC ON; B/W : 0 lux with IR
Scanning System Progressive Scan
Lens
Focus Length 3.6mm
Focus Control Fixed
Lens Type Fixed
Night Vision
IR Cut Filter YES
Infrared LED 42µ x 2PCS
Infrared Distance 25M
IR Status AGC Auto Control
Camera Features
Starlight N/A
Day/Night YES
OSD Menu YES
WDR DWDR
UTC YES
Noise Reduction DNR
Coaxial Audio YES(only TVI )
White Balance AUTO / MANUAL
Gain Control AUTO
General
Housing Front Cover: Metal ,Back Cover: Plastic, IP67
Bracket YES
Operation Temperature -10℃ ~ +60℃ RH95% Max
Storage Temperature -20℃ ~ +60℃ RH95% Max
Power Source DC12V±10%, 450mA
Dimension 176.6(W) x 67(H) x 70(D)mm
Weight 336g
